R801 Tube Hi-Fi Stereo Classic Radio AM/FM Short Wave Tube Radio also can be used as an integrated tube radio -- you can hook speakers to this unit ....... Features:

  • With 7 pcs of Vacuum Tube improves "Digital Sound" effectively
  • Stereo Sound with excellent effect
  • FM / AM / SW1 / SW2 function
  • Magnetically shielded drivers, virtually eliminates monitor and TV screen interference.
  • All MDF wood enclosures.
  • Magic Eye
  • Volumes and power switch located on Front panel.
  • Unique, Classical & Elegant appearance.
  • Exclusive product unique worldwide
  • High quality and good price
  • Can be used as a separate tube amplifier.

Specifications:

Receiving Scope:

  • AM Scope:535KHz~1610KHz
  • FM Scope:: 88 MHz~108MHz
  • SW1 Scope:: 4.5MHz~12.5MHz
  • SW2 Scope:: 12.5MHz~22MHz

    Tube Amplifier :
  • Output Power: = 2x18W (1KHz THD=10%)
  • Frequency Response:30Hz~20KHz
  • AM?SW Frequency Response:60Hz~8KHz (+3/-5dB)
  • FM Frequency Response:60Hz~15KHz (+3/-5dB)
  • Vacuum Tube: 6L6×4 6F2×2
  • 6E2(Magic Eye)

    Speaker Unit:
  • Bass Speaker Size: 2 x 5.25"
  • Treble Speaker Size: 2 x 1"
  • Speaker Rated Power:=20W
  • Speaker Impedance: 8O
  • Speaker Frequency Response:80Hz~15KHz
  • Input Port: CD (DVD) Aux RCA in
  • Output Port: Earphone Out, Rec. Out & 2.0 Speaker Out
  • Product Size: 54(L) x W33(W) x 25(H) cm
